Pro-NM Slits Spatial Resolution Phantom

Pro-NM Slits Spatial Resolution Phantom

Slits phantom for Intrinsic Spatial Resolution evaluation (Quantitative technique) according to NEMA Standards Publication NU 1-2012. In addition to this standard size phantom, we offer different sizes and configurations manufactured to the highest quality standards.

Brand

Model

Pro-NM Slits
Add to Quote
Categories: , , ,

Slits phantom for Intrinsic Spatial Resolution evaluation (Quantitative technique) according to NEMA Standards Publication NU 1-2012. In addition to this standard size phantom, we offer different sizes and configurations manufactured to the highest quality standards.



Features

Complies with:

  • NEMA Standards Publication (NU 1-2001) Performance Measurements of Scintillation Cameras
  • NEMA Standards Publication (NU 1-2012) Performance Measurements of Scintillation Cameras
  • CE certified the manual provides detailed guidelines for carrying out each test, results assessment and registration

Specifications

Technical Data (can be modified to customer specifications):

Dimensions: 564 x 432 x 15 mm

Lead size: 539 x 405 x 3 mm parallel 1 mm thick slits with 30 mm spacing cover made of PMMA uniform PMMA part of the phantom

Measurements

Dimensions: 564 x 432 x 15 mm

Lead size: 539 x 405 x 3 mm
