Polisimeter Electronic Personal Dosimeter

PoliSimeter offers enhanced capabilities for the extended measurement of personal dose Hp(10) and dose rate Ḣp(10) of both continuous and pulsed X-ray and gamma radiation. The PoliSimeter is designed to meet the latest industry requirements and features a USB-C port for convenient connectivity and data transfer.

Brand

Model

PM1610
Add to Quote
Categories: , ,

X-ray (continuous/pulsed) and gamma radiation personal dosimeter.

PoliSimeter™ series of electronic personal dosimeters (EPDs) is the next generation of the well-known PM1610 series by Polimaster, which was a trusted solution on the market for nearly 15 years, with over 20,000 dosimeters sold. Building on the legacy of the PM1610, the PoliSimeter offers enhanced capabilities for the extended measurement of personal dose Hp(10) and dose rate Ḣp(10) of both continuous and pulsed X-ray and gamma radiation. The PoliSimeter is designed to meet the latest industry requirements and features a USB-C port for convenient connectivity and data transfer.

Features

  • Wide dose and dose rate measurement ranges
  • Long-life rechargeable battery: 500 hours
  • Measurement of pulsed photon radiation
  • Simple navigation with two large buttons
  • Audible, visual, and vibration alarms
  • USB-C communication with PC
  • Shockproof hermetic case
  • Small and lightweight

Specifications

Detector

Geiger-Mueller tube

Dose indication range

0.001 µSv to 12 Sv

Dose measurement range

0.05 µSv to 10 Sv

Dose rate indication range

0.01 µSv/h to 12 Sv/h

Dose rate measurement range

0.1 µSv/h to 10 Sv/h

Dose rate linearity (0.1 µSv/h to 1 Sv/h)

-13 % to +18 %
IEC 61526:2024 compliant

Accuracy (Ref. 137Cs at 300 µSv/h)

±5 %

Statistical fluctuations for dose and dose rate

IEC 61526:2024 compliant

Energy range

20 keV to 10 MeV

Combined energy and angular response (Ref. 137Cs)

−29 % to +67 % (48 keV to 1.25 MeV; 0° to 60°)
IEC 61526:2024 compliant

Pulsed radiation
– pulse width
– dose range

>1 ms
10 µSv to 10 Sv

Alarms

visual, audible, vibration

Thresholds

2 independent thresholds for both dose and dose rate

Memory

7500 events

PC communication

USB-С

Power supply

built-in rechargeable battery

Battery lifetime

500 hours (typical)

*When the average dose rate is not more than 0.2 µSv/h; backlight and alarms are activated for not more than 20 s per 24 hours

Ingress protection

IP65

Drop test

1 m (concrete surface)

Dimensions

58 × 58 × 20 mm

Weight

70 g

Operating temperature

–20 °С to 50 °С

Atmospheric pressure

84 to 106.7 kPa

Humidity

up to 98 % at 35 °С

Applications

  • Customs and border control
  • Healthcare professionals
  • Nuclear power plants
  • Emergency services
  • Police and security
  • Industrial facilities
  • First responders
