ECORAY-ORANGE-1040-HF-VET-Portable-Vet-X-Ray

ECORAY ORANGE 1040 HF VET Portable Vet X-Ray

Orange 1040HF portable x-ray is applicable to veterinary purposes and it is light, compact and powerful. It is a significant step up from the 9020 and is still easily carried from one place to another weighing 12.5kg.

Brand

Model

ORANGE
Code

ECOORANGE1040HF
Part Number

1040HF
Add to Quote
Categories: , , , ,

ECORAY’s high frequency inverter technology is heading to more valuable, durable and powerful to produce the high quality of images with every imaging solution. With an increased output suitable for all veterinary and equine applications.

Great Selection for Veterinary.

  • Power into a compact body (2.4kWk, 100kV/40mA output))
  • Robust & light weight with higher mA range up to 40mA
  • Wide range of application : from equine lower limb to small animal surgery
  • Reliable performance

Features

Key Features

  • Powerful & Stable output with unique features for user convenience
  • Portable X-ray generators for veterinary purposes
  • Compact size but powerful output 100kV/40mA
  • Outstanding & Stable imaging capability
  • Ergonomic & Soft OP panel layout
  • Easy access to DR systems with FPD
  • Convenient handling for advanced image quality
  • In the box: Aluminum Carry Case, Spare Globe, Spare Fuse

Operation Switch

  1. kV & mAs Up/Down
  2. Built in dual laser & Collimator lamp ON/OFF
  3. Reversible Display
  4. APR memory storage

Specifications

  • Generator Type: Monobloc design, High Frequency Inverter
  • HV Generator: 2.4kW (80kv@30mA)
  • Max kV / mA: 100kV / 40mA
  • Increments: 40 – 100kV in 1kV Steps
  • X-Ray Tube Focal Spot: 1.2mm x 1.2mm
  • Increments: 0.32 – 100 mAs (26 Steps)
  • mA Available: 20, 26, 30, 35, 40mA
  • SID measurement: Tape & Laser Pointer
  • Memory: 8 APR (Extendible to 16)
  • Weight: 11.7 kg
  • Power requirements: 2.4kVa, 230VAC, 10A, 50Hz
  • Size: 344x191x188mm
  • Warranty: 2 Year Warranty
